high performance low profile CPU cooler
• Suitable for HTPC or slim system with limited space
• High performance low profile four direct contact heatpipes cooler
Only 57mm tall,
suitable for HTPC or
slim system with limited space
High performance low profile
four direct contact heatpipes cooler
Low noise
12cm slim PWM fan

Socket Type Intel LGA775, LGA1150, LGA1151, LGA1155, LGA1156, LGA1200, LGA1366, AMD Socket AM2, AM2+, AM3, AM3+, AM4, FM1, FM2, FM2+
Suggestion TDP (W) 95
Cooler Dimension 120 x 120 x 57 mm
Heatsink Material Aluminium fins with copper heatpipes
Installation Mounting screw and bracket kit
Weight 282g
Product Code AK-CC4016EP01

Dimension 120 x 120 x 15 mm
Bearing EBR Bearing
Fan Speed 600 - 1800 RPM
Max Airflow 61.37 CFM
Max Air Pressure 1.72 mm-H2O
Noise Level 32.9 dB(A)
Current Rating for Fan 0.33A
Voltage Rating for Fan DC 12V
Fan Connector 4-pin PWM
Fan Life Expectancy 40,000 hours
Warranty 2 years

Installation manual

GB, FR, DE, PT, ES, JP, CH

- 2015-02-05

We would suggest a maximum of 95W TDP with good airflow.
