Designed to perform
  massive airflow to tame
those overclocked chips
  space for up to four
hi-end VGA cards
  no cable mess with
holes in the MoBo tray
and routing behind the
  the ultimate
gaming case,
and revolutionary

top: 23cm fan (included)
or 2 x 12 / 14cm fan (optional)
  side: 4 x 12cm fan or
1 x 18-23cm fan (optional)
front: 23cm fan with
white LED (included)
  buttom: 1 x 12 / 14cm fan (optional)
back: 14cm fan (included)
or 12cm fan (optional)


fan controller on front
panel with USB 3.0 and
eSATA port
  HDD trays support 3.5" or 2.5" HDD/SSD
tool-free 5.25” device installation   tool-free PCI slots installation
rubber slots for cable
  supports high-end long VGA cards up to 330mm
dust filter for base vents   top panel storage area
watercooling access holes with rubber grommets


Colour Smooth black with killer yellow
Material SECC 0.8 / 1.0mm
Compatible motherboard types Micro ATX / ATX / E-ATX / XL-ATX
5.25" external bays 6
3.5" external bays 1
3.5" internal bays (2.5" HDD/SSD supported) 6
Cooling system
1 x 23cm fan with white LED (included)
1 x 23cm fan (included) or
2 x 12cm fan (optional) or
2 x 14cm fan (optional)
1 x 14cm fan (included) or
1 x 12cm fan (optional)
4 x 12cm fan (optional) or
1 x 18-23cm fan (optional)
1 x 12cm (optional) or
1 x 14cm fan (optional)
Fan specifications Top panel : 1 x 23cm exhaust fan
Front panel : 1 x 23cm input fan with white LED
Back panel : 1 x 14cm exhaust fan
Fan controller Controls 6 fans simultaneously with 40W combined maximum wattage
PSU (not included) Supports ATX and EPS power supplies
Base mounted, dual positioning
Dust filter supplied
I/O Ports 2 x USB 3.0 , 2 x USB 2.0 , 1 x eSATA , HD audio in / out (AC’97 compatible)
Expansion slots 10
Dimensions 591 x 555 x 232mm(H x D x W)
Weight 12.6kg
Product Code AK-STR-01BK

Installation manual
